Leírás
A termék NEM
tartalmazza, az akkumulátorokat, és a tárolóegységet!
PN
PWUP-OL06KBA-AZ01B
EAN6422956006341
Type
On-line
Power
6000 VA / 6000 W
Nominal Input Voltage
208/220/230/240 VAC
Nominal Output Voltage
208/220/230/240 VAC
Accepted Input Voltage Range
110~300 VAC at 0~60% Load
140~300 VAC at 60~80% Load
176~300 VAC at 80~100% Load
Frequency
46~54 Hz at 50Hz
Outlets
Terminal Block Wiring
Transfer Time to Battery / AC
Zero
Communication Port
RS232 / USB / Intelligent Port (not included in the package)
Efficiency
Up to 94% efficiency rate
Battery Type
Battery not included
Depends on Balder Battery Pack
Battery Specification
Compatible with Balder Battery Pack 2U (16 batteries of 7Ah/9Ah)
Compatible with Balder Battery Pack 3U (20 batteries of 7Ah/9Ah)
Features
True Double Conversion Technology
Optional N+X parallel redundancy
High efficiency up to 94%
Software Management Output Power Factor 1.0
DSP technology guarantees high performance
Wide input voltage range (110-300 VAC)
Higher output crest ratio 3:1
Emergency power off function (EPO)
User-friendly and easy-shift LCD
Rack/Tower design
Software
Software management included
LCD Display
AC Mode, Battery Mode, Load Level, Battery Level, Input Voltage, Output Voltage, Overload, Fault and Low Battery
Operation Temperature
0 ~ 40 C
Physical Dimensions
2U
